主要用于高速DAC/ACC/AOC(QSFP28、SFP28、uQSFP、QSFP-DD、OSFP、SFP+、QSFP+、Slim-SAS、Mini-SAS、Mini-SAS HD等)。它是集SI測試、EEPROM寫/讀、測試數據可追溯性、報表生成和標簽打印等為一體的自動化測試管理系統。它可以顯著提高測試效率、準確性，并且可以在世界的每個角落跟蹤我們的產品的數據。
1、Support all Keysight / R&S PNA;
2、20/26.5/40GHz RF Switches matrix (5 million lives) to allow for up to 4*20 Channel automatic test;
3、High test accuracy, supporting 8/16 thru channel calibration, which improve the consistency of multi-channel testing;
4、Project management, allow test spec editing and report automatic output;
5、With AFR, COM, Timedomain, EEPROM write/read etc. many functions;
6、Very fast test time, 2 Channel less than 30s, 8 Channel with noise less than 120s
7、Upload data to database, very convenient query and traceability
8、Support IL, RL, ILD, ILfit, Diff Impedance, Common impedance, NEXT, FEXT, MDNEXT, MDFEXT, ICN, ICR, Skew, Delay etc.
